12V-24V-36V-48VPWM Brush Motor Controller/Reversing, Enable / Brake / Direction Terminals

Speed Control12V-24V-36V-48VPWM Brush Motor Controller/Reversing, Enable / Brake / Direction Terminalsvariety of control mode: potentiometer analog control pulse width controlWide Input RangeSmall sizeTECHNICAL PARAMETERSSoft start time: 0.2-5SSoft stop time: 0.2-5SAnalog control signal: 0-5V (wired to earth ground)Signal input impedance more than 200KSpeed accuracy: 1%Speed adjustable range: 100:1Speed Ratio: 1:80Ambient temperature: 0 Celsius degree - 50 Celsius degreeRelative Humidity: Below dew pointWeight:300gFEATURESseries drive is DC-4Q Regenerative & Braking Reversible PWM series Drive, it has quickly dynamic response, smooth operating, works well and perfect functions.Pulse Width Modulation Motor runs quieter, with greater efficiency and less maintenance, longer life.Four Quadrant Regenerative OperationRegenerative BrakingNo contactors required. No electromechanical components to overheat or wear out.ENABLE / BRAKE / DIRECTION TERMINALSChoose a function by simply opening or closing a dry contact or through an open collector transistor.Status LEDsPower and Fault LEDs provide a visual status of the drive.Forward and reverse can be set separatelyOutput current can be setBraking current can be set compensation functionStandard analog control mode:Analog: 0-5V or potentiometerOver Temperature ProtectionDrive will fold the output power back to prevent from overheating. Drive will fault if it still remains too .==========Model Number : DC12/48RT50BL-XWMotor Type : MotorAmbient temperature: : 0- 80weight : 300gdimension : 123mm * 85mm * 42mmType : Motor Controllerinput volt : 12-48VDCout put volt : 0-48VDCrated current : 20Acontroller current : 40Acontrol mode : 0-10V or potentiometer
