1PCS 1/2" inch Single Acting Pneumatic Angle seat Valve NC(Tri-clamp)

Filter ValvesPneumatic angle seat single acting spring return pneumatic valves use compressed air to open the piston valve and close the valve via a spring built into the pneumatic actuator. Industrial pneumatic valves are used to control the opening and closing of valves for air, gas, liquid, water, steam and other media. Pneumatic piston angle seat valves are characterized by the fact that the valve can operate at very high temperatures, high viscosity media and is less sensitive to dirt particles and debris.Series pneumatic angle seat valve specifications:Valve type: two normally closedUsing medium: air, gas, liquid, water, steam, oil, vacuumOperating mode: Pneumatic single acting (spring return)Actuator working pressure: 100 PSIActuator operating pressure range: 65 - 120 PSIMain body material: 316 stainless steel/CF8MActuator material: CF8Sealing material: polytetrafluoroethylene (PTFE)Valve seat material: polytetrafluoroethylene (PTFE)Control medium: inert air, airWorking Pressure: Vacuum to 240 PSIMaximum viscosity: 600 mm2/s (600 centistokes)Media temperature: -20 to 180 °C (-5 to 350 °F)Ambient temperature: -20 to 60 °C (-5 to 140 °F)Installation direction: any positionPort size: 1/2" NPT female port standardMounting Hardware: 1 piece Tube 1/4" OD X Thread 1/8" Male Straight Connector Accessory
