2.8-inch LCD Digital Multimeter 20000 Counts True RMS Portable High Precision Universal Tester Voltmeter Ammeter Voltage Meter

Material: ABSRange: Manual rangeDisplay Count: 20000Sampling Rate: 3 times/sAC Voltage Range: 200mV±(1.0%+25), 2V/20V/200V±(0.8%+25), 1000V±(1.2%+25)AC Voltage Resolution: 0.01mV/0.0001V/0.001V/0.01V/1VAC Voltage(LPF): 200V/1000V±(2%+30)AC Voltage(LPF): 0.01V/0.1V Voltage Range: 200mV/2V/20V/200V±(0.05%+5), 1000V±(0.1%+5) Voltage Resolution: 0.01mV/0.0001V/0.001V/0.01V/1VAC Current Range: 2000uA/200mA±(1.5%+15), 20A±(2.5%+35)AC Current Resolution: 0.1uA/0.01mA/0.001A Current Range: 200uA/2000uA±(0.5%+4), 200mA±(0.8%+6), 20A±(2%+15) Current Resolution: 0.01uA/0.1uA/0.01mA/0.001AResistance Range: 200Ω±(0.4%+10), 2kΩ/20kΩ/200kΩ/2MΩ±(0.4%+5), 20MΩ±(1.2%+25), 200MΩ±(5%+10)Resistance Resolution: 0.01Ω/0.0001kΩ/0.001kΩ/0.01kΩ/0.0001MΩ/0.001MΩ/0.1MCapacitance Range: 20nF/200nF/2000nF/2uF/20uF/200uF/2mF±(4%+50), 20mF/200mF±(10%)Capacitance Resolution: 0.001nF/0.01nF/0.1nF/0.0001uF/0.001uF/0.01uF/0.1uF/0.001mF/0.01mFFrequency Range: 200Hz~60MHz±(0.1%+3)Frequency Resolution: 0.01Hz~0.01MHzTemperature Range:-40~40℃±4%, 40~400℃±(1%+5℃), 400~1000℃±(2%+5℃)-40~104℉±5℉, 104~752℉±(1.5%+5℉), 752~1832℉±(2.5%+5℉)Temperature Resolution: 0.1℃/℉Conductance: 200nS±(1.2%+50)Conductance Resolution: 0.01nSContinuity Test: 200ΩContinuity Test Resolution: 0.01ΩDiode Test: 20VDiode Test Resolution: 0.001VPacking List:1 * Multimeter1 * Pair of Test Lead1 * K-type Temperature ProbeNote: Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!Please allow 1-3mm measuring deviation due to manual measurement.High-definition backlight display: high-definition backlight easy to deal

• Multiple Functions: including the measurement functions of DC/AC voltage, DC/AC current, resistance, capacitance, conductance, frequency, temperature, continuity & diode test, and LPF measurement.
• Wide Measurement Range: 0.1nS~200nS conductance measurement, 200MHz frequency measurement for sinusoidal/non-sinusoidal waves (such as crystal frequency), 1000V max. measurable AC/DC voltage, 20A max. measurable current, very large capacitance (200mF) measurement, etc.
• Safety : full-featured false detection protection for up to 600V overvoltage surge, and overvoltage/overcurrent alarm.User-friendly Design: injection molding case with high hardness that can bear from dropping from 1 meters hight.
• Clearly Measured Data Checking: 2.8-inch large LCD display with auto backlight for flexibly responding to various dark conditions. And the data hold function for writing the measurement value down with ease.
• Other Features: 20000-count display, true RMS measurement, and fast ADC (3 times/s), peak maximum/minimum capture, auto power off, audible & visual alarm, etc.
• Power on that is measured: gear automatic jump, voltage, AC voltage, on-off, resistance power on that is measured
