ABB Miniature Circuit Breaker, 60 VDC, 15 A, 14 kA Interrupt, 1 Poles
4.8 (90 items)
Limited Time Sale$50.39 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210098532 | Release Date | 2026/04/02 | List Price | $33.60 | Model Number | 210098532 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
System pro M compact S200UDC current limiting miniature circuit breakers are specially designed for DC applications in the scope of UL489. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload Protection and the electro mechanic tripping mechanism for short circuit Protection. They are available in different characteristics (K, Z), configurations (1P, 2P) and rated currents (up to 63 A).The Short-circuit current rating SCCR according to UL489 is 14 kA. The S200UDC is suitable for DC voltages up to 125 VDC (2P). All MCBs of the product Range S200UDC comply with UL489, allowing the use for commercial and industrial applications.Type K tripping characteristicFor use as a branch circuit Protection deviceCurrent limitingFast breaking time (2.3 - 2.5 ms)Bus connection systemAvailable with variable depth handle mechanismFinger safe terminalsMulti-function terminalsSuitable for reverse feedContact Position indication - On-OffScrew terminal type - cable clamp2.8 Nm tightening torqueActuator type - Insulation Group II, black, sealable
| Voltage | 60 Volts |
|---|---|
| Brand Name | ABB |
| Item Weight | 30.5 Pounds |
| Part Number | S201UDC-K15 |
| Manufacturer | ABB |
| Mounting Type | DIN Rail Mount |
| Current Rating | 15 Amps, 63 Amps |
| Number of Poles | 1 |
