AT3816B 10Hz-200kHz LCR Meter, 0.1% Accuracy Inductance-Capacitance-Resistance Measurement, Dual Displays, Comparator and Processor Interfaces, for Passive Component Testing and Classification

The AT3816B is an advanced benchtop LCR meter ideal for precise measurement and sorting of passive components. It covers a wide 10Hz to 200kHz test frequency range with high basic accuracy of 0.1%. Inductance, capacitance, resistance and dissipation factor can be reliably measured. Dual large color LCD displays allow clear viewing of primary and secondary parameters. Automatic, manual and nominal range selection provides flexibility. The built-in comparator and handler interface enables automatic sorting when connected to a PLC. SCPI and Modbus remote interfaces allow data collection and analysis. Up to 10 test frequencies can be programmed for customized testing. DC bias up to ±2.5V characterizes polarized components. With its wide frequency range, high accuracy, dual display, auto sorting capability, and DC bias, the AT3816B is perfect for production testing, quality control, and lab use. Specifications: - 10Hz to 200kHz frequency range - 0.1% basic accuracy - Measures L, C, R, D - Dual color LCD display - Auto, manual, nominal ranging - Comparator & handler interface - SCPI & Modbus interfaces

• TOP SPECIFICATIONS:The Digital Instrument boasts impressive specifications, including a high accuracy of 0.1%±5 digits, a wide frequency range from 50Hz to 200kHz with 37 points, and the capability to measure various parameters such as inductance, capacitance, and resistance. The automatic, manual, and nominal range settings (9 ranges) provide flexibility for diverse testing needs.
• PURPOSE AND FUNCTIONALITY:Designed for both laboratory quality control and electronic component classification, this upgraded digital instrument serves as a versatile tool for testing inductance, capacitance, and resistance. With added features like DCR measurement and internal DC bias (±2.5V), it meets the demands of a range of applications, making it an essential tool for electronics enthusiasts, engineers, and professionals.
• ADVANTAGES OF THE PRODUCT:The Digital Instrument offers several advantages, including simultaneous testing of four parameters, each customizable as per user requirements. The inclusion of a color LCD display, English operation, and large font enhances user experience. The built-in comparator with automatic sorting capabilities, in conjunction with PLC integration, streamlines component classification. Additionally, the ALC function ensures signal level control, contributing to accurate and relia
• PARAMETERS AND MATERIALS:The digital instrument covers an extensive range of parameters, including Cs-Rs, Cs-D, Cp-Rp, Cp-D, Lp-Rp, Lp-Q, Ls-Rs, Ls-Q, G-B, R-X, Z-θrad, Z-θdeg, and more. It supports various output impedances (30Ω, 50Ω, 100Ω) and offers DC bias capabilities from -2.5V to +2.5V. The robust design and use of quality materials ensure durability and longevity, making it a reliable tool for consistent and accurate measurements.
• APPEARANCE AND PACKAGING:The Digital Instrument features a compact design with dimensions of 264(W) x 107(H) x 350(D) mm and a weight of 4 kg, making it portable and easy to handle. The product comes with an upgraded appearance, highlighted by a colorful LCD display. The packaging is designed to protect the instrument during transit and includes user-friendly documentation, ensuring a seamless unboxing experience for buyers.
