Battery Capacity Tester Discharger,Electronic Load 0.1-40A Large Current Lithium Battery Charge Discharge Capacity Tester,for Battery Testing

Intelligent battery capacity test discharger Iron lithium battery lead-acid polymer manganate battery testing machine 12V 72VSpecification:Name: EBD-B10H battery capacity testerPower: 880WBattery group Capacity test: 12-72VDischarge: 0.5-10AVoltage setting: 9.00-88.00V, minimum step 0.01VCurrent setting: 0.50-10.00A, minimum step 0.01A (maximum 5A for 12V battery group)Voltage measurement: 0.10-89.00V, accurate to 0.01V, error +-0.5%Current measurement: 0.50-10.00A, accurate to 0.01A, error +-0.5%Packing size: 44*29*27cmWeight: 6.5kgPackage List:1 x Battery Tester1 x Online cable1 x Testing cable1 x Power supply cableNotes:1. Due to manual measurement, 2-3cm deviation is allowed.2. Different monitors have different calls, and the product color is subject to the actual product.

• This is a capacity tester for lead-acid and lithium-ion batteries. It is suitable for battery capacity test in the range of 12V-72V. It has built-in discharge load resistor and supports computer online drawing curve.
• Wiring method: four-wire detection, voltage measurement and current channel separate wiring to ensure measurement accuracy.LCD display: test data such as voltage, current, capacity, time, etc.
• Computer connection: dedicated USB to TTL serial cable. Computer control, plotting curves, calibrating measurement benchmarks, upgrading device firmware
• Test mode: DSC (constant current discharge), the measured voltage will automatically stop when it is lower than the set termination voltage.
• Capacity measurement:10Ah, resolution 0.001Ah,10Ah-100Ah, resolution 0.01Ah,100Ah or more, resolution 0.1Ah
