Clamp Earth Resistance Tester Ground Resistance Tester Grounding Resistance Measurement Instrument with Resistance Range 0.010Ω-1200Ω Leakage Current Range 0.00mA-20.0A

YFYIQI Clamp Earth Resistance Tester Meter Ground Resistance Tester Grounding Resistance Measurement Instrument with Resistance Range 0.010Ω-1200Ω Leakage Current Range 0.00mA-20.0A Alarm Threshold Setting 1-199Ω Specification: ❤Clamp Size:65mm×32mm ❤LCD Size:4 Digits LCD display, Screen: 47mm×28.5mm ❤Range: Resistance: 0.010Ω~1200Ω Current: 0.00mA~20.0A ❤Resolution:Resistance: 0.001Ω; Current: 0.05mA ❤Accuracy:Resistance: ±1%±0.01Ω; Current:±2.5%±1mA ❤Data Storage: 99 sets ❤Auto Power-off:Automatically power off after 5 minutes without any operate ❤Power Consumption:≤50mA， continuously working for 30 hours ❤Alarm Threshold Setting Range:Resistance：1~199Ω ❤Audible and VisibleAlarm: “Beep-beep-beep” alarm sound, alarm symbol flashing, pressALkey to turn on/off and setting ❤Protection Level: Double insulation ❤Structural Feature:Clamp CT ❤Shift:Automatic shift ❤External Magnetic Field:＜40A/m ❤External Electrical Field:＜1V/m ❤Single Measurement Time: 0.5 second ❤Resistance Measurement Frequency: ＞1KHz ❤Measured Current Frequency:50/60Hz Automatic ❤Low Battery Voltage Indication:When the battery voltage is lower than 5.3V, the low battery voltage symbol is displayed ❤Storage Full Indication:Storage data full of 99 sets,flashed display "MEM" symbol ❤Tester Weight:1160g ❤Tester Dimension:285mm×85mm×56mm

• It is widely used in the grounding resistance measurement of the power, telecommunications, meteorology, oilfield, construction and the industrial and electrical equipment.
• (2)In the measurement of a grounding system with loop, does not require breaking down the grounding down lead, and no need the auxiliary electrode. It is safe, fast and simple in use. The tester can measure ground faults which cannot be measured by traditional methods.
• (3)Breakthrough in self-test the boot a long time to waiting, start immediately into the test. Breakthrough relay self-test mode, using the most advanced processing algorithms and digital integration technology.
• (4)Measurement resistance range: 0.01Ω-1200Ω and current range :0.00mA~20.0A .Stored data 99 Units. Lower power consumption, Maximum operating current less than 50mA.
• (5)Breakthrough the old product to heavy issues, more in line with characteristics of hand-held devices.New design, panel operation with 6 buttons, better performance.
