Clean Room Differential Pressure Monitor (Temp, RH, Diff. Pressure) for Hospitals,Green House Alongwith Factory Calibration Certificate Model: AI-CRM3-1-1 (External Sensor)

The Ace AI-CRM 3-1-1 Pharma Clean Room Monitor features an external sensor for humidity and temperature, which is integrated into the monitor itself. This allows the display to be placed outside the operation theatre or clean room while the external sensor continuously measures the environmental conditions. The differential pressure sensor is also having with the Clean Room Monitor, with 2 hose nipples for connecting the room and corridor.

• Model: AI-CRM3-1-1 | Measuring Parameters: Temperature, Humidity, Differential Pressure | Temperature Range: -30.0 to +50.0 Deg.C / -22°F to 122°F; Accuracy: ± 0.5°C; Resolution: 0.1°C | Humidity Range: 0.0 to 100.0%RH; Accuracy: ± 1.8% for 10 to 95% RH; Resolution: 0.1% RH | Differential Pressure Range: -500 to +500 pascals; Accuracy: +/- 0.5% F.S; Resolution: 1 pascal |
• Display: 3 Line Red 7 segment LED display of Height 0.8” | Differential Pressure Entry: 2 Nos. 4 mm. Hose nipples at top of clean room monitor enclosure entry | Setting: By 4 keys inside the instrument | Buzzer: Integrated buzzer for alarm Hi & Lo in case of process violation of any of the 3 parameters | Supply Voltage: 24VDC, 500mA |
• Mounting: Wall mounting / Modular Wall mounting with stainless steel front flush plate for clean rooms | External Humidity & Temperature Sensor in Stainless Steel Front Flush Plate Enclosure 2) Built-in differential pressure sensor with Brass Hose Nipples (Chrome Plated) for Differential Pressure at rear (4mm X 2 Nos.) |
• Communication : RS 485 communication | Enclosure: M.S. Powder coated body with stainless steel front plate for Modular wall mounting/ optional brick wall mounting | Dimensions: Enclosure: 110(W) X 150(H) X 30(D) mm. & Stainless-Steel front plate: 180(W) X 200 (H) mm. | weight: 700 gms. Approx.
• Supply Scope: 1 Unit of AI-CRM3-1-1 Clean Room Monitor, Power Adaptor, Instruction Manual wall mount hose nipples and Factory Calibration Certificate | Applications: Pharma Clean Rooms, Hospitals, API’s, Bulk Drugs, Green House, Test Plants, Electronic Hardware manufacturing plants.
