Cole-Parmer Very-Low Differential Pressure Transmitter, 0.5" WC, 0-5VDC

Low-pressure transucers sense gauge or differential pressure and convert to a proportional output. Utilizing an improved stainless steel micro-tig welded sensor, positive pressure moves the diaphragm toward the electrode, increasing capacitance. A decrease in pressure moves the diaphragm away from the electrode, decreasing the capcitance. Change in capacitance is converted to a linear DC electrical signal through the transducer''s circuit. Transducers are designed for HVAC, air volume and fan control, static duct and clean-room pressures, and environmental pollution control. SpecificationsMin Pressurein WC: -0.5 Max Pressurein WC: 0.5 Accuracy: ±1.0% full-scale Battery Type: 24 VDC Electrical Connections: 3-wire Media Compatibility: Nonconducting gases Output: 1 to 5 VDC Process Connection: 1/4 (in) hose barb Description: Very-Low Differential Pressure Transmitter, 0.5 (in) WC, 0-5VDC Universal Guarantee: 1 year

• Uni- and bi-directional pressure measurement offer high accuracy for building energy management
• Static accuracy of ±1%
• Fully protected against reverse wiring
• Fire retardent case is UL 94 V-0 approved
