FPV High Resolution Thermal Imager 256 * 192/384 * 288/640 * 512 CVBS Camera,Compatible For Drone(384x288 CVBS 9.1MM)

Specifications: Resolution: 256 x 192 - Detector Type: Vanadium Oxide Non-Cooled Infrared Focal Plane Detector - Effective frame rate: 50 fps - Pixel pitch: 12 µm - NETD: 40mk - Spectral band: 8 - 14 µm - Objective Parameters: F1.0/4.3mm F1.0/6.8mm F1.0/9.1mm - Field of View (HxV): 4.3mm: 45°(H) x 33°(V) 6.8mm: 26°(H) x 20°(V) 9.1mm: 18.1°(H) x 13.6°(V) - Polarity/palette: white heat, black heat, fusion, iron red, fusion CVBS only emits white heat and black heat. Power supply: 5V-20V - Power: 0.65W - Output: CVBS - Analog Video: PAL - Product size (without lens): 21 mm x 21 mm. - Weight (without lens): 23 g - Operating temperature: -40~80 - Storage temperature: -50~80 Specifications: Resolution: 384 x 288 - Detector Type: Vanadium Oxide Non-Cooled Infrared Focal Plane Detector - Effective frame rate: 60 fps - Pixel pitch: 12 µm - NETD: 40mk - Spectral band: 8 - 14 µm Objective Parameters: F1.0/9.1mm - Field of view (HxV): 9.1 mm: 26.46°(H) x 19.81°(V) - Polarity/palette: white heat, black heat, fusion, iron red, fusion CVBS only emits white heat and black heat. Power supply: 5V-20V - Power: 0.65W - Output: CVBS - Analog Video: PAL - Product size (without lens): 21 mm x 21 mm. - Weight (without lens): 23 g - Operating temperature: -40~80 - Storage temperature: -50~80 Specifications: Resolution: 640 x 512 - Detector Type: Vanadium Oxide Non-Cooled Infrared Focal Plane Detector - Effective frame rate: 60 fps - Pixel pitch: 12 µm - NETD: 40mk - Spectral band: 8 - 14 µm - Lens Parameters: F1.0/9.1mm - Field of view (HxV): 9.1 mm: 48.3°(H) x 38.6°(V) - Polarity/palette: white heat, black heat, fusion, iron red, fusion - CVBSonly has white heat and black heat. - Power Input: 5V - 20V - Power: 0.65W - Output: CVBS - Analog Video: PAL - Product size (without lens): 21 mm x 21 mm. - Weight (without lens): 23 g - Operating temperature: -40~80 - Storage temperature: -50~80

• This FPV thermal imaging device features a high-resolution detector (256x192 / 384x288 / 640x512) to capture clear and detailed temperature data.
• Equipped with a CVBS camera output, ensuring wide compatibility with various video viewing and recording systems.
• Designed for seamless integration with compatible drone platforms, enhancing aerial observation capabilities.
• The imager provides real-time temperature display, ideal for inspection, search and observation tasks.
• Built with a durable housing to withstand the demands of air operations and outdoor use.
