Hantek Qingdao USB/PC Oscilloscopes Hantek6074BD/6104BD/6204BD/6254BD Portable Oscilloscopes Kit PC 70MHz~250MHz 4CH Handheld Oscilloscope DDS/Arb Waveform Generator(Hantek6074BD)

Qingdao Hantek6004BD Series* 4CH oscilloscope & function/Arb. waveform generator. * The performance of this model could even better than the performance of benchtop oscilloscope. * Function/Arbitrary Waveform Generator: 200MSa/s DDS, 12bits of vertical resolution, built-in variety of standard * Pass/fail test, resourceful trigger function, dynamic cursor tracking, waveform record and replay function. * USB2.0 Interface, plug and play device. * Good mechanical design with small size which is easy for carrying. The outer case is made by the same material with - Anodised aluminium. * Fit for the portable computers, table PC, and repairing/fixing of production line. Suitable for business trip use. * Software support: Windows10, Windows 8, Windows 7* The waveform data could be output to EXCEL,BMP,JPG as time and voltage category. * More than 20 kinds of automatic measurement function, PASS/FAIL Check function, fit for engineering application. * Serial bus triggering and decode, Bus protocol information can be quickly and intuitively displayed in table form. * Waveform averaging, afterglow, lightness control, reverse, add, subtract, multiply, divide, X-Y display. * FFT spectrum analyzer* One computer could connect with multiple oscilloscopes, expand the channel number easily. * Provide secondary development library DLL; Provide Labview\VB\VC developing examples. *

• *The performance of this model could even better than the performance of benchtop oscilloscope
• *Pass/fail test, resourceful trigger function, dynamic cursor tracking, waveform record etc
• *USB2.0 Interface, plug and play device.
• *Good mechanical design with small size which is easy for carrying.
• *Fit for the portable computers, table PC, and repairing/fixing of production line.
