Heavy Duty Series Compact OEM Pressure Transmitters (Range: 0 to 60Bar) (Without Reducer, (0-60 bar)) | Industrial Pressure Transmitter | Gems Sensors 3200
4.7 (42 items)
Limited Time SaleUntil the end
01
30
18
$83.40 cheaper than the new price!!
Free shipping for purchases over $99 ( Details )
Free cash-on-delivery fees for purchases over $99
Free cash-on-delivery fees for purchases over $99
See all stores
Please note that the sales price and tax displayed may differ between online and in-store. Also, the product may be out of stock in-store.
New $139.00
Product details
| Management number | 211153484 | Release Date | 2026/04/04 | List Price | $55.60 | Model Number | 211153484 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Range: 0 to 60Bar; Accuracy: 0.25% FS for >1000 psi (60 bar), 0.50% FS for <1000 psi (60 bar); Performance: Long Term Drift: 0.2% FS/YR (non-cumulative).
- Thermal Error: 2% FS/100°C for <1000 psi (60 bar); Operating Temperatures -40°F to +257°F (-40°C to +125°C) for elec. codes B, C, E, G, 6, 8, 9, Y -5°F to +180°F / (-20°C to +80°C) for elec. codes F, 3, W; Storage Temperatures: -40°F to +257°F / (-40°C to +125°C).
- Zero Tolerance: 0.50% of span for >1000 psi (60 bar), 1.00% of span for 1000 psi (60 bar), 1.00% of span for <1000 psi (60 bar); Response Time: 1ms; Fatigue Life: Designed for more than 100M cycles; Voltage: Output (3-wire) 0 V min. to 10 V max; Supply Voltage 2 Volts above full scale to 30 VDC max @ 4.5 mA (6.5 mA on dual output version); Source and Sinks: 2 mA.
- Current: Output (2-wire): 4-20 mA; Supply Voltage: 8 to 30V DC; Maximum Loop Resistance: (Supply Voltage-8) x 50 ohms; Ratiometric: Output 0.5 to 4.5 VDC @ 4 mA (6.5 mA on dual output version); Supply Voltage: 5V DC ±10%.
- Mechanical Configuration: Wetted Parts: 17-4 PH Stainless Steel; Housing: 304 Stainless Steel; Enclosure: IP67 (IP65 for electrical codes G & W); Vibration: 40G peak to peak sinusoidal,(Random Vibration: 20 to 1000 Hz @ approx. 40G peak per MIL-STD-810E); Shock: Withstands free fall to IEC 68-2-32 procedure 1; EMC (Radiated Immunity) 100 V/m.
| Manufacturer | INSTRUKART |
|---|
