LLPT Double Sided Thermal Tape 1.2" x 108 Ft Strong Adhesive for Electronic Components LED Strips Heat Sinks(TC128)

PRODUCT FEATURES:: - Coated with strong Acrylic adhesive on both sides. - High thermal conductivity, flexibility, insulation and long life support. - Widely used in LED lighting, automotive electronics, household electrical appliances, consumer electronic devices, power devices, PDP/LED TV, communication, computer/laptop like CPU, GPU, USICS, RDRAMTM, CD-ROM, IGPT module & hard drives. - Work temperature range: -20°C to 120°C. - Extra thickness, 12 mil; appropriate heating low temperature will increase greatly on stability and durability in the area of adhesive. - Meets ASTM D5470, industrial grade especially for electronic industry. - White color with blue backing liner protective film. - Packed in single PE bag. - Available Size: 1.2” width x 108 feet long and 1.6” width x 108 feet long. SPECIFICATION: : - Width: 1.2” and 1.6” are available. - Length: 108 feet. - Thickness: 12 mil with 2.7 mil blue backing liner. - Adhesive Strength: 5lbs/square inch. - Adhesion: >20N/1.2 inch width; >25N/1.6 inch width. - Stripping Strength: PSTC-101, >17N. - Breakdown Voltage: 6KVAC. - Thermal Coefficient: 1.5 W/M-K. - Work Temperature: -20°C to 120°C. - Thermal Impedance: 0.3°C In 2/W. - Tension: PSTC-7, >48 HRS. - Material: Fiberglass with conductive ceramic powder.

• APPLICATION: LLPT 2-sided thermal adhesive tape meets ASTM D5470 with high coefficient for thermal conduction on electronic components, like controller, semiconductor, MOS, IC, GBT, SSD, computer CPU, GPU, RAM & DDR memory modules and so on; easy mountings to replace screws for electronic components to increase the work efficiency, printing industry, filling gap on uneven surfaces of electronic components for tight fit, holding LED strips and etc.
• MATERIAL: LLPT double sided thermal conductive tape is a combination of fiber glass that fills conductive ceramic powder for high efficiency and flexibility of thermal conduction & insulation; coated with strong Acrylic adhesive, removable, repositionable and residue free for easy mountings to save time and work better on electronic.
• EASY USE: Ideal to mount heat sink to IC chip, fit parts to heating source devices and hold LED strips; clean the dust before application and cut the size as needed, stick and compress the tape, then take off the blue backing film liner by hand to mount another part. The removable property is to allow reposition after application without any damages to components. Avoid finger prints on adhesive layer for strong holding.
• FEATURE: LLPT Thermal Conductive tape has high thermal conductivity, insulation, strong adhesive, flexibility, compression, high tensile strength to hold the components firmly in place, have the most effective thermal dissipation and widely used in electronic devices.
• EFFICIENT HEAT TRANSFER: LLPT double sided thermal tape facilitates effective heat transfer between heat sinks and electronic components, ensuring optimal cooling performance in electronic devices, computers, LED lights, and more, enhancing reliability and longevity.
