(Pack of 1) Heavy Duty Pressure Transmitter Transducer (Range: 0 to 16 bar/232 PSI) G ¼ Thread with 4-20mA for Industrial, Hydraulic Applications & HVAC by | Model: MBS 3000
4.0 (103 items)
Limited Time Sale$84.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211699094 | Release Date | 2026/04/04 | List Price | $56.00 | Model Number | 211699094 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Measuring range: 0 to 16 bar | Operating Temperature: -40 °C to +85 °C | Accuracy (incl. non-linearity, hysteresis and repeatability) ≤ ± 0.5% FS (typ.) & ≤ ± 1% FS (max.) | Standard Output Signal: 4-20 mA | Pressure Connection: G 1/4
- Measuring range: 0 to 16 bar | Operating Temperature: -40 °C to +85 °C | Accuracy (incl. non-linearity, hysteresis and repeatability) ≤ ± 0.5% FS (typ.) & ≤ ± 1% FS (max.) | Standard Output Signal: 4-20 mA | Pressure Connection: G 1/4
- Burst pressure: 6 × FS (max. 2000 bar) | Power-up time: < 50 ms | Durability, P: 10 – 90% FS >10 × 106 cycles | Sensor Operating temperature: Normal: -40 to 85 °C & ATEX Zone 2: -10 to 85 °C
- Insulation resistance: > 100 MΩ at 500 V DC | Enclosure: IP65 | Net weight (depending on pressure connection and electrical connection): 0.2 – 0.3 kg | Temperature compensated and laser calibrated
- Supply Scope: 1 unit of MBS3000 pressure transmitter and Instruction manual | Applications: Pumps, Compressors, Pneumatics, Water treatment, Automobiles, Heavy Industries & HVAC.
