Precise Ultrasonic Flaw Detector Detection Location Defectoscope Scanning with Range 0 to 25000mm A Scan B Thickness Color Grey Scan 4 Scanning Mode Video Time 160 Min DAC/AVG Curve USB 2.0

HFBTE Precise Ultrasonic Flaw Detector Detection Location Defectoscope Scanning With Range 0 To 25000mm A Scan B Thickness Color Grey Scan 4 Scanning Mode Video Time 160 Min DAC/AVG Curve USB 2.0Features:The Digital Ultrasonic Flaw Detector offers high speed, high accuracy, high efficiency,high reliability, and real-time operation in a digital interface. The detector contains the most up-to-date technology and has the following features:◆A user-oriented interface with a multi-function shortcuts, menu operation and a rotating navigation wheel.◆A 5.7-inch TFT color screen with adjustable color and bright settings.◆A small and light portable battery that can be charged anytime for use in any environment.◆Multi-channel testing with the option to save channels.◆Large capacity for waveform storage and the ability to load waveforms.◆The capacity to record and store high-speed videos.◆Automatic readings capture with moving gates.◆Adjust the gain conveniently using gain subtraction shortcuts (users can also access the preset parameters with one key).◆Automatic calibration for various probe parameters.◆A no order limit for point in DAC and AVG curves.◆Fully adjustable pulse transmission (amplitudes and widths) with built-in support to block pulses and transmit sharp pulses.◆Impedance matching for different requirements of sensitivity and resolution.◆Four work modes: normal probe, angle probe, dual-crystal straight probe and transmission probe.◆ Receive and amplify signals：→ Real-time sample: high speed ADC, wave detail fully displayed.→ Rectification: full, positive, negative, reflective.→ Gate: dual-gate, support time gate and sound path gate, echo capture automatically.→ Gain: Multi-grade adjustable, basic gain, scan gain, compensation gain, support locked gain and auto gain;◆Alarm function: beep alarm and flash alarm.◆Digital display zoom: change the font size in parameters menu.◆Real-time stopwatch function: track and save time records.◆USB functionality: data transfer via high-speed USB.◆Power saving: screen brightness will automatically decrease or shut off to save power and extend product life.◆Detection features:→ Peak-value recording: record and save the maximum values of defect recording in real-time.→ Echo envelope: receive detailed information on peak trace depiction for defect echo.→ Crack height measurement: automatically measure and calculate crack height.→ B-SCAN: real-time scanning of cross-sectional shape to directly display the shape of the workpiece. Includes thick B-SCAN (both models) and color B-SCAN ， Grey B-SCAN.→ Aperture: auto-calculate aperture flaws (i.e. Ф values)→ AWS function: directly display defect classifications.→ Weld diagrammatic presentation: directly display the sectional distribution of weld defects during weld testing→ Automatic DAC and AVG generation: automatically find the highest wave of the defect and automatically calculate equivalent Ф by normal/angle probe.→ Video function: record, save and play waveform in real-time.→ Defect location: values for horizontal value (L), depth (H) and sound path (S).→ Defect quantitative analysis: flexible display according to an adjustable reference.→ Defect qualitative analysis: real-time estimates and judgements of envelope waveform.→ Curved surface correction: automatic correction and conversion of curved surfaces→ Broadening function: user-adjustable ability to broaden the waveform selection.→ Echo code: different echoes distinguished by different colors.Technical Specifications◆Scanning range:0～25000 mm◆Frequency:0.2~20MHZ◆Gain:0 dB～110 dB◆Velocity:200～20000 m/s◆Channel Storage:100◆Waveform Storage:1000◆Record Storage:60min+5min×20◆Display Delay:-20µs～+3400 µs◆Probe Delay:0.000~99.99 µs◆Bandwidth:0.2MHZ~15MHZ◆Vertical Linerarity Error:≦3%◆Horizontal linerity Error:≦0.1%◆Dynamic Range:100db◆Rectification:Positive Half Wave, Negative Wave, Full Wave and RF◆Test Mode:Pulse-echo, dual and through transmission◆Probe Damping DD:100Ω, 150Ω, 200Ω, 500Ω◆Sensitivity:>62db (Depth: 200mm, Flat-Bottom Hole dia 2mm)◆Standard Configuration: Main Unit (Flaw Detector ), Angle Probe K2, 2.5P, 13*13mm, TR-Probe F20mm, 2.5P, Li-Batteries, AC Charger, BNC connection Cable, Manual, Software, Case

• High-Quality Display: Features a 5.7-inch TFT color screen with adjustable color and brightness settings for optimal visibility in various working conditions
• Advanced Scanning Capabilities: Equipped with dual-gate functionality, thickness measurement, and color B-scan technology for comprehensive flaw detection
• Extended Video Recording: Offers video recording time up to 160 minutes for thorough documentation of inspection processes and results
• Intelligent Measurement Features: Includes curved surface correction and automatic measurement and calculation of crack height for accurate defect analysis
• DAC/AVG Curve Functionality: Provides DAC and AVG curve generation for precise defect evaluation and quantitative analysis of flaws
• Real-Time Wave Detection: Automatically searches for the highest wave and records the maximum value of defects in real-time for efficient inspection
• Peak Trace Depiction: Features peak trace depiction for defect echo, providing detailed information for accurate defect judgment and classification
• Long Battery Life: Powered by a high-capacity lithium battery with low power consumption design, delivering up to 20 hours of continuous operation
• Multiple Scanning Modes: Supports A scan, B color scan, B Thickness Scan, and B Grey Scan for versatile inspection applications across different materials
• Data Transfer Capability: USB 2.0 connection enables easy upload of inspection data to PC for analysis, storage, and reporting purposes
