STC-1000 LED Digital Temperature Controller Thermostat Incubator Aquarium Thermoregulator 10A Heating Cooling Relay AC220V DC12V(STC-1000 DC 12V)

Thermostat ControllersSTC-1000 LED Digital Temperature Controller Thermostat Incubator Aquarium Thermoregulator 10A Heating Cooling Relay Coontrol AC110-220V DC12V 24VFeatures:1. Switch between Heating and Cooling Modes2. Control temperature by setting the temperature value or difference value of temperature3. Temperature calibration function4. Refrigerating control output delay protection5. Alarm when temperature exceeds limit or sensor error6. Memory function: settings can be saved when power off7. Wide Application: domestic freezer, refrigerator, industrial chiller, steamer, industrial equipment and other temperature control applicationsParameters:Item No.: STC-1000Display: Modes: Heating and CoolingTemperature Measuring Range: -50 ~ 99Accuracy: ±0.1 (-50 ~ 70)Resolution: 0.1Working Temperature: 0 ~ 60Relative Humidity: 20~85% (no condensation)Sensor error delay: 1 minutePower Supply: AC 110V~220V / DC12V/ DC24V<; 3WOutput Relay: 2 Relays: Cooling & Heating both 10A220VACNTC Probe Sensor 100cmDelay start and temperature calibration Function YESMounting Hole Size: 71x29mmDimension: 75x34.5x85mm (LxWxH)Note: the sensor can not put in the water for a long timeMenu Instruction:CodeFunctionSet RangeDefaultF1Set Temperature Value-50.0 ~ 99.910.0F2Set Difference Value of Temperature0.3 ~ 10.00.5F3Compressor Delay Time1~10 Minutes3 minutesF4Temperature Calibration Value-10.0 ~ 10.00Packing List:1x Temperature Controller + 1x NTC Probe Sensor + 1x ManualPanel IllustrationPower Switch Set Key UP Key Down KeyIndicator Light Measured Temperature NTC Probe SensorIndicator Light Status InstructionIndicator LightFunctionCool Indicator LightOn: Refrigeration starts / Off: Refrigeration stops / Flash: compressor DelayHeat Indicator LightOn: Heating starts / Off: Heating stopsSet Indicator LightOn: Parameter setting statusKey operation instruction1 .The way to check parameter:Under normal working status, press "up" key it displays temperature setting value; press "down" key it displays the difference value.2. The way to set parameter:Under controller normal working status, press "s"key for 3s or more to enter parameter modifying mode, and the "Set" indicator light on, screen displays the first menu code "F1".Press "up"key or "down" key to adjust up and down and display the menu iem and the code of the menu item. Press "s" key to display the parameter value of the current menu. Press both "s"key and hold "up"key or "down" key simultaneously to choose and adjust the parameter value of the current menu value promptly. After finishing the setting, press and release the "(I)" key instantly to save the parameter modified value and to display the normal temperature value. If no key operation within 10 seconds, system won't save modified parameter, screen back to display normal temperature.3. Restore system dataWhen electrified, system will check itself, screen will display "Er" if error exit, please press any key at this time, and it restores default value and enter into normal working mode, it is advised to reset the parameter value under such conditions.Operation instructionUnder controller normal working status, press and hold "(I)"key for 3s can turn off the controller; Under controller "off" status, press and hold "(I)" key for 1s can turn on the controller.Under the controller normal working status, screen displays the current measuring temperature value; also the controller can also switch the working mode between heating and cooling.Controller starts refrigerating with cool indicator light on when the measuring temperature value >= temperature set value + difference value, and the refrigerating relay is connected; If the "Cool" indicator light flashes, it indicates the refrigerating equipment is under compressor delay protect status; when the measuring temperature values temperature set value, the Cool indicator light on, and refrigerating relay disconnects.System starts heating when the measuring temperature value <;= the temperature set value-difference value, and the "Heat" indicator light on, the heat relay connects; When the measuring temperature >= temperature set value, the "Heat" indicator light is off, and the heat relay disconnects.Error/Alarm descriptionAlarm when sensor error: Controller activate the sensor error alarm mode when sensor open circuit or short circuit, all therunning status is closed off with the buzzer alarms, and the nixie tube displays "EE",Press any key can cancel alarm sound, system back to display the normal temperature when the error and the fault is cleared.Alarm when the measuring temperature exceeds temperature measuring range:Controller activates the error alarm functionwhen the measuring temperature exceeds the temperature measuring range, all the running status is closed off with the buzzeralarms, and the nixie tube displays "HH",Press any key can cancel alarm sound, system back to display the normal working mode when the temperature restore to normal measuring range.Safety RegulationsDanger:1. Strictly distinguish the sensor down-lead, power wire and output relay interface from one another, and prohibit wrong connections or overloading the relay.2. Dangers: Prohibit connecting the wire terminals without electricity cut-off.Warning:Prohibit using the machine under the environment of over damp, high temp., strong electromagnetism interference orstrong corrosion.Notice:1.The power supply should conform to the voltage value indicated in the instruction.2.To avoid the interference, the sensor down-lead and power wire should be kept a distance.Wiring WaysIndependent power supply for loadSame power supply for load
