Surpass Hobby Brushless Motor and ESC Combo Set 3665 3800KV Brushless Motor with110A ESC Suitable for 1/10 Car (3665 3800KV 110A)

Specification:Item Type: 3665 Brushless MotorMaterial: Aluminum Alloy + Copper + PlasticColor: BlackMotor Model: 3665KV (RPM/Volt): 3800KVWattage: 1400WMaximum Voltage: 14VMaximum Current: 90AMaximum Speed: 50000No Load Current: 4.2ANumber of Motor Poles: 4Internal Resistance (Ω): 0.0042Motor Length: Approx. 65mm / 2.55in (Without Shaft)Motor Diameter: Approx. 36mm / 1.4inShaft Diameter: Approx. 5mm / 0.196inShaft Length: Approx. 17mm / 0.66inGold Plated Plug: Approx. 4.0mm / 0.16in110A ESC:Continuous Current: 110AInstantaneous Current: 520AMotor Type: Non Inductive Brushless MotorInternal Resistance: 0.0004ohmBattery: 2-3S Lithium Battery / 4-9S NiMHBEC Output: 6V/7.4/8.4V/6A (Switching Mode)Product Size: Approx. 50x35x34mm / 2.0x1.38x1.34inPlug Type: XT60 to T Plug ConnectorApplication: for 1/10 Remote Control Car (eg: for Tamiya / for Traxxas)Package List:1 x 3660 Brushless Motor1 x 110A ESC1 x XT60 to T Plug Connector4 x Screw2 x ManualNote:1. Due to manual measurement, please allow an error of 13mm. Thanks!2. The monitor calibration is inconsistent, the color of the item shown in the photo may be slightly different from the actual object3. Please unload the cooling fan water before using this ESC; clean and wipe dry as soon as possible after use to prevent the connector from rusting.4.Genuine Surpass Hobyy RC products,exquisite workmanship & durable.buy with conf

• High protection Functions: all-weather operation The IP-67 waterproof Rating guarantees excellent waterproof and dustproof protection. The whole power system is able to drive on a variety of surfaces including mud, sand, ice, snow and water without damaging the power unit.
• Premium Material: High balance explosion-proof rotor, high accuracy and high speed, dynamic balance control within 10mg. excellent performance, high magnetic permeability, high silicon content, good insulation and heat resistance.
• Stability and Reliability: Adopt lnfineon mosfet chip,Intelligent freewheeling technology, greatly improved performance The innovative intelligent freewheeling technology enables higher driving efficiency and lower operating temperature of the ESC, and further improves the stability and reliability of the ESC.
• Capacitor Thermal Protection: High quality ruby capacitors,capacitor thermal protection is designed and implemented into the ESC to effectively prevent capacitors from exploding and causing irreversible damages to the ESC due to overloading.
• Profession: Powerful built-in BEC The ESC has a built-in BEC with a continuous current of 6A. The output voltages are switchable between 6V, 7.4V 8.4V. This ensures that the ESC is able to support the demanding high-torque servos in the market.
