USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM
USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM

USB Logic Analyzer Device 24MHz 8CH 8 Channel UART IIC SPI Debug with mini USB Cable Dupont Cable 6 Colors Test Hook Clip Set for Arduino FPGA M100 SCM

flash sale iconLimited Time Sale
Until the end
09
58
42

$54.00 cheaper than the new price!!

Free shipping for purchases over $99 ( Details )
Free cash-on-delivery fees for purchases over $99
See all stores
Please note that the sales price and tax displayed may differ between online and in-store. Also, the product may be out of stock in-store.
New  $90.00
quantity

Product details

Management number 211161520 Release Date 2026/04/04 List Price $36.00 Model Number 211161520
Category
  1. Industrial & Scientific
  2. Test, Measure & Inspect
  3. Electrical Testing
  4. Logic Analyzers

Product description This item is an inexpensive logic analyzer designed to be compatible with Saleae Logic Analyzer software. Specifications: Works with 5V, 3.3V, 2.5V, 2.0V systems. May work with 1.8V but not recommended Input Impedance: 1Mohm || 10pF (typical, approximate) Crystal: +/-20ppm, 24MHz Error/Accuracy: pulse-width measurement: +/- 42ns (at 24MHz) Voltage range: Input voltage range: -0.5V to 5.25V Input Low Voltage: -0.5V to 0.8V Input High Voltage: 2.0V to 5.25V Input Impedance: 1Mohm || 10pF (typical, approximate) Package Included: 1 x Logic Analyser 1 x MINI USB Cable 1 x 22PIN Female and female DuPont cable 12 x Test Hook Clip

  • Product introduction: This item is an inexpensive logic analyzer designed to be compatible with Saleae Logic Analyzer software.
  • Applicable to various occasions: The logic sampling rate of each of the 8 channels is 24M/s, generally about 10M, which is sufficient for various occasions
  • Channel value: A total of 8 digital channels, the voltage range is 0V and 5.5V, of which 1.5V is the voltage threshold, below 1.5V is considered low, above 1.5V is considered high.
  • Sampling rate up to: 24 MHz , can be 24MHz. 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz.
  • Automatic analysis: UART, SPI, IIC and other communication debugging, let you get twice the result with half the effort. 24M sampling rate, can automatically analyze UART, IIC, SPI and many other standard protocols.
Color Mini interface
Model JK-US-155
Brand Name DKARDU
Unit Count 1.0 Count
Item Weight 0.1 Kilograms
Manufacturer DKARDU
Power Source Corded Electric
Measurement Type Logic Analyzer
Specification Met Ul 61010-1, Iec 61010-2-030
